本文展示如何分类猫与狗图像，使tf.keras.preprocessing.image.ImageDataGenerator加载数据，构造tf.keras.Sequential模型进行分类。你将获得一些实践经验，并发展以下概念的直觉:
- 使用tf.keras.preprocessing.ImageDataGenerator构建数据输入管道。ImageDataGenerator可以使Model有效处理磁盘上的数据。
- 过拟合 – 如何识别并防止
本教程遵循一个基本的机器学习工作流程:
- 检查和理解数据
- 构建输入管道
- 构建模型
- 训练模型
- 测试模型
- 改进模型并重复该过程
def loadDataDir():
_URL = 'https://storage.googleapis.com/mledu-datasets/cats_and_dogs_filtered.zip'
path_to_zip = tf.keras.utils.get_file('cats_and_dogs.zip', origin=_URL, extract=True)
print(path_to_zip)
PATH = os.path.join(os.path.dirname(path_to_zip), 'cats_and_dogs_filtered')
print(PATH)
# 设置训练集与验证集的路径
train_dir = os.path.join(PATH, 'train')
validation_dir = os.path.join(PATH, 'validation')
train_cats_dir = os.path.join(train_dir, 'cats') # directory with our training cat pictures
train_dogs_dir = os.path.join(train_dir, 'dogs') # directory with our training dog pictures
validation_cats_dir = os.path.join(validation_dir, 'cats') # directory with our validation cat pictures
validation_dogs_dir = os.path.join(validation_dir, 'dogs') # directory with our validation dog pictures
# os.listdir 获取路径下的文件
num_cats_tr = len(os.listdir(train_cats_dir))
num_dogs_tr = len(os.listdir(train_dogs_dir))
num_cats_val = len(os.listdir(validation_cats_dir))
num_dogs_val = len(os.listdir(validation_dogs_dir))
total_train = num_cats_tr + num_dogs_tr
total_val = num_cats_val + num_dogs_val
print('total training cat images:', num_cats_tr)
print('total training dog images:', num_dogs_tr)
print('total validation cat images:', num_cats_val)
print('total validation dog images:', num_dogs_val)
print("--")
print("Total training images:", total_train)
print("Total validation images:", total_val)
return train_cats_dir, train_dogs_dir, validation_cats_dir, validation_dogs_dir将图像格式化为适当的预处理后的浮点张量，然后再传送到网络:
- 从磁盘读取图像。
- 解码这些图像的内容，并转换成适当的网格格式，根据他们的RGB内容。
- 把它们转换成浮点张量。
- 归一化： 将张量从0到255之间的值缩放到0到1之间的值，因为神经网络更喜欢处理小的输入值。
幸运的是，所有这些任务都可以使用tf.keras提供的ImageDataGenerator类来完成。它可以从磁盘读取图像并将其预处理成适当的张量。它还将设置生成器，将这些图像转换成有助于训练网络的批量张量。
def createGenerator(train_dir, validation_dir):
# 创建ImageDataGenerator
# from tensorflow.keras.preprocessing.image import ImageDataGenerator
train_image_generator = ImageDataGenerator(rescale=1. / 255) # Generator for our training data
validation_image_generator = ImageDataGenerator(rescale=1. / 255) # Generator for our validation data
# 使用generator， 从磁盘加载图片
train_data_gen = train_image_generator.flow_from_directory(
batch_size=batch_size,
directory=train_dir,
shuffle=True,
target_size=(IMG_HEIGHT, IMG_WIDTH),
class_mode='binary'
)
val_data_gen = validation_image_generator.flow_from_directory(
batch_size=batch_size,
directory=validation_dir,
target_size=(IMG_HEIGHT, IMG_WIDTH),
class_mode='binary')
return train_data_gen, val_data_gen
Found 2000 images belonging to 2 classes.
Found 1000 images belonging to 2 classes.# 抽取部分数据，做可视化展示
# next函数从数据集中获取一个彼此数据, 返回(x_train, y_train), x_train是特征，y_train是标签，此处丢弃标签，只展示图片
sample_training_images, _ = next(train_data_gen)
plotImages(sample_training_images)
def createModel():
model = Sequential([
Conv2D(16, 3, padding='same', activation='relu', input_shape=(IMG_HEIGHT, IMG_WIDTH ,3)),
MaxPooling2D(),
Conv2D(32, 3, padding='same', activation='relu'),
MaxPooling2D(),
Conv2D(64, 3, padding='same', activation='relu'),
MaxPooling2D(),
Flatten(),
Dense(512, activation='relu'),
Dense(1, activation='sigmoid')
])
return model# 编译model
model.compile(
optimizer='adam',
loss='binary_crossentropy',
metrics=['accuracy']
)
model.summary()
Model: "sequential"
_________________________________________________________________
Layer (type) Output Shape Param #
=================================================================
conv2d (Conv2D) (None, 150, 150, 16) 448
_________________________________________________________________
max_pooling2d (MaxPooling2D) (None, 75, 75, 16) 0
_________________________________________________________________
conv2d_1 (Conv2D) (None, 75, 75, 32) 4640
_________________________________________________________________
max_pooling2d_1 (MaxPooling2 (None, 37, 37, 32) 0
_________________________________________________________________
conv2d_2 (Conv2D) (None, 37, 37, 64) 18496
_________________________________________________________________
max_pooling2d_2 (MaxPooling2 (None, 18, 18, 64) 0
_________________________________________________________________
flatten (Flatten) (None, 20736) 0
_________________________________________________________________
dense (Dense) (None, 512) 10617344
_________________________________________________________________
dense_1 (Dense) (None, 1) 513
=================================================================
Total params: 10,641,441
Trainable params: 10,641,441
Non-trainable params: 0
_________________________________________________________________
None
# 训练模型
total_train_num = len(os.listdir(train_cats_dir)) + len(os.listdir(train_dogs_dir))
total_val_num = len(os.listdir(validation_cats_dir)) + len(os.listdir(validation_dogs_dir))
history = model.fit_generator(
train_data_gen,
steps_per_epoch=total_train_num,
epochs=epochs,
validation_data=val_data_gen,
validation_steps=total_val_num
)def visualizeTrainResults(history):
acc = history.history['accuracy']
val_acc = history.history['val_accuracy']
loss = history.history['loss']
val_loss = history.history['val_loss']
epochs_range = range(epochs)
plt.figure(figsize=(8, 8))
plt.subplot(1, 2, 1)
plt.plot(epochs_range, acc, label='Training Accuracy')
plt.plot(epochs_range, val_acc, label='Validation Accuracy')
plt.legend(loc='lower right')
plt.title('Training and Validation Accuracy')
plt.subplot(1, 2, 2)
plt.plot(epochs_range, loss, label='Training Loss')
plt.plot(epochs_range, val_loss, label='Validation Loss')
plt.legend(loc='upper right')
plt.title('Training and Validation Loss')
plt.show()
在上图中，训练集的准确性呈线性增长，但是验证集最终停止在70%，这显示过拟合。
1.7、数据增强(Data Augmentation)过拟合通常是由于训练数据少，通过增加训练数据来结果该问题。Data Augmentation从现有的数据集中生成更多的训练数据，
通过horizontal_flip 设置到ImageDataGenerator实现该扩展。
def da1():
train_image_generator = ImageDataGenerator(rescale=1. / 255, horizontal_flip=True) # 水平翻转
# 使用generator， 从磁盘加载图片
train_data_gen = train_image_generator.flow_from_directory(
batch_size=batch_size,
directory=train_dir,
shuffle=True,
target_size=(IMG_HEIGHT, IMG_WIDTH),
class_mode='binary'
)
# 抽取同一个图像，重复5次, 以便对同一个图像进行五次增强
augmented_images = [train_data_gen[0][0][0] for i in range(5)]
# 可视化
plotImages(augmented_images)
def da2():
train_image_generator = ImageDataGenerator(rescale=1. / 255, rotation_range=45) # 随机旋转图像，此处设置45度
# 使用generator， 从磁盘加载图片
train_data_gen = train_image_generator.flow_from_directory(
batch_size=batch_size,
directory=train_dir,
shuffle=True,
target_size=(IMG_HEIGHT, IMG_WIDTH),
class_mode='binary'
)
# 抽取同一个图像，重复5次, 以便对同一个图像进行五次增强
augmented_images = [train_data_gen[0][0][0] for i in range(5)]
# 可视化
plotImages(augmented_images)
def da3():
train_image_generator = ImageDataGenerator(rescale=1. / 255, zoom_range=0.5) # 放大增强
# 使用generator， 从磁盘加载图片
train_data_gen = train_image_generator.flow_from_directory(
batch_size=batch_size,
directory=train_dir,
shuffle=True,
target_size=(IMG_HEIGHT, IMG_WIDTH),
class_mode='binary'
)
# 抽取同一个图像，重复5次, 以便对同一个图像进行五次增强
augmented_images = [train_data_gen[0][0][0] for i in range(5)]
# 可视化
plotImages(augmented_images)
def da4():
train_image_generator = ImageDataGenerator(rescale=1. / 255,
rotation_range=45, # 随机旋转，最大45度
width_shift_range=.15, # 宽度转变
height_shift_range=.15, # 高度转变
horizontal_flip=True, # 水平翻转
zoom_range=0.5) # 放大增强
# 使用generator， 从磁盘加载图片
train_data_gen = train_image_generator.flow_from_directory(
batch_size=batch_size,
directory=train_dir,
shuffle=True,
target_size=(IMG_HEIGHT, IMG_WIDTH),
class_mode='binary'
)
# 抽取同一个图像，重复5次, 以便对同一个图像进行五次增强
augmented_images = [train_data_gen[0][0][0] for i in range(5)]
# 可视化
plotImages(augmented_images)
在这里，你应用dropout到第一和最后的最大池层。应用dropout将随机设置20%的神经元在每个训练阶段为零。这有助于避免对训练数据集的过度拟合。
model_new = Sequential([
Conv2D(16, 3, padding='same', activation='relu',
input_shape=(IMG_HEIGHT, IMG_WIDTH ,3)),
MaxPooling2D(),
Dropout(0.2), # Dropout,
Conv2D(32, 3, padding='same', activation='relu'),
MaxPooling2D(),
Conv2D(64, 3, padding='same', activation='relu'),
MaxPooling2D(),
Dropout(0.2), # Dropout
Flatten(),
Dense(512, activation='relu'),
Dense(1, activation='sigmoid')
])
新的训练结果
