生成用于ASP.NET Web API的TypeScript客户端API

#if DEBUG  //This controller is not needed in production release,
	// since the client API should be generated during development of the Web Api.
...

namespace Fonlow.WebApiClientGen
{
    [System.Web.Http.Description.ApiExplorerSettings(IgnoreApi = true)]//this controller is a
			//dev backdoor during development, no need to be visible in ApiExplorer.
    public class CodeGenController : ApiController
    {
        ///
        /// Trigger the API to generate WebApiClientAuto.cs for an established client API project.
        /// POST to  http://localhost:10965/api/CodeGen with json object CodeGenParameters
        ///
        ///
        /// OK if OK
        [HttpPost]
        public string TriggerCodeGen(CodeGenParameters parameters)
        {
...
        }
    }

备注

//config.SetDocumentationProvider(new XmlDocumentationProvider
(HttpContext.Current.Server.MapPath("~/App_Data/XmlDocument.xml")));

取消注释，使其像这样：

config.SetDocumentationProvider(new XmlDocumentationProvider
(HttpContext.Current.Server.MapPath("~/bin/Your.WebApi.xml")));

在项目“属性”页面的“Build”选项卡中，检查“输出/XML文档文件”并设置“bin\Your.WebApi.xml”，而输出路径默认情况下为“bin”。

namespace DemoWebApi.DemoData
{
    public sealed class Constants
    {
        public const string DataNamespace = "http://fonlow.com/DemoData/2014/02";
    }

    [DataContract(Namespace = Constants.DataNamespace)]
    public enum AddressType
    {
        [EnumMember]
        Postal,
        [EnumMember]
        Residential,
    };

    [DataContract(Namespace = Constants.DataNamespace)]
    public enum Days
    {
        [EnumMember]
        Sat = 1,
        [EnumMember]
        Sun,
        [EnumMember]
        Mon,
        [EnumMember]
        Tue,
        [EnumMember]
        Wed,
        [EnumMember]
        Thu,
        [EnumMember]
        Fri
    };

    [DataContract(Namespace = Constants.DataNamespace)]
    public class Address
    {
        [DataMember]
        public Guid Id { get; set; }

        public Entity Entity { get; set; }

        ///
        /// Foreign key to Entity
        ///
        public Guid EntityId { get; set; }

        [DataMember]
        public string Street1 { get; set; }

        [DataMember]
        public string Street2 { get; set; }

        [DataMember]
        public string City { get; set; }

        [DataMember]
        public string State { get; set; }

        [DataMember]
        public string PostalCode { get; set; }

        [DataMember]
        public string Country { get; set; }

        [DataMember]
        public AddressType Type { get; set; }

        [DataMember]
        public DemoWebApi.DemoData.Another.MyPoint Location;
    }

    [DataContract(Namespace = Constants.DataNamespace)]
    public class Entity
    {
        public Entity()
        {
            Addresses = new List();
        }

        [DataMember]
        public Guid Id { get; set; }


        [DataMember(IsRequired =true)]//MVC and Web API does not care
        [System.ComponentModel.DataAnnotations.Required]//MVC and Web API care about only this
        public string Name { get; set; }

        [DataMember]
        public IList Addresses { get; set; }

        public override string ToString()
        {
            return Name;
        }
    }

    [DataContract(Namespace = Constants.DataNamespace)]
    public class Person : Entity
    {
        [DataMember]
        public string Surname { get; set; }
        [DataMember]
        public string GivenName { get; set; }
        [DataMember]
        public DateTime? BirthDate { get; set; }

        public override string ToString()
        {
            return Surname + ", " + GivenName;
        }

    }

    [DataContract(Namespace = Constants.DataNamespace)]
    public class Company : Entity
    {
        [DataMember]
        public string BusinessNumber { get; set; }

        [DataMember]
        public string BusinessNumberType { get; set; }

        [DataMember]
        public string[][] TextMatrix
        { get; set; }

        [DataMember]
        public int[][] Int2DJagged;

        [DataMember]
        public int[,] Int2D;

        [DataMember]
        public IEnumerable Lines;
    }

...
...

namespace DemoWebApi.Controllers
{
    [RoutePrefix("api/SuperDemo")]
    public class EntitiesController : ApiController
    {
        ///
        /// Get a person
        ///
        /// unique id of that guy
        /// person in db
        [HttpGet]
        public Person GetPerson(long id)
        {
            return new Person()
            {
                Surname = "Huang",
                GivenName = "Z",
                Name = "Z Huang",
                BirthDate = DateTime.Now.AddYears(-20),
            };
        }

        [HttpPost]
        public long CreatePerson(Person p)
        {
            Debug.WriteLine("CreatePerson: " + p.Name);

            if (p.Name == "Exception")
                throw new InvalidOperationException("It is exception");

            Debug.WriteLine("Create " + p);
            return 1000;
        }

        [HttpPut]
        public void UpdatePerson(Person person)
        {
            Debug.WriteLine("Update " + person);
        }

        [HttpPut]
        [Route("link")]
        public bool LinkPerson(long id, string relationship, [FromBody] Person person)
        {
            return person != null && !String.IsNullOrEmpty(relationship);
        }

        [HttpDelete]
        public void Delete(long id)
        {
            Debug.WriteLine("Delete " + id);
        }

        [Route("Company")]
        [HttpGet]
        public Company GetCompany(long id)
        {

以下JSON配置数据将POST到CodeGen Web API：

{
    "ApiSelections": {
        "ExcludedControllerNames": [
            "DemoWebApi.Controllers.Account",
            "DemoWebApi.Controllers.FileUpload"
        ],

        "DataModelAssemblyNames": [
            "DemoWebApi.DemoData",
            "DemoWebApi"
        ],

        "CherryPickingMethods": 3
    },

    "ClientApiOutputs": {
        "ClientLibraryProjectFolderName": "..\\DemoWebApi.ClientApi",
        "GenerateBothAsyncAndSync": true,
        "CamelCase": true,

        "Plugins": [
            {
                "AssemblyName": "Fonlow.WebApiClientGen.jQuery",
                "TargetDir": "Scripts\\ClientApi",
                "TSFile": "WebApiJQClientAuto.ts",
                "AsModule": false,
                "ContentType": "application/json;charset=UTF-8"
            },

            {
                "AssemblyName": "Fonlow.WebApiClientGen.NG2",
                "TargetDir": "..\\DemoNGCli\\NGSource\\src\\ClientApi",
                "TSFile": "WebApiNG2ClientAuto.ts",
                "AsModule": true,
                "ContentType": "application/json;charset=UTF-8"
            }
        ]


    }
}

建议将JSON配置数据保存到Web API项目文件夹中的此类文件中。

///
/// Flagged options for cherry picking in various development processes.
///
[Flags]
public enum CherryPickingMethods
{
    ///
    /// Include all public classes, properties and properties.
    ///
    All = 0,

    ///
    /// Include all public classes decorated by DataContractAttribute,
    /// and public properties or fields decorated by DataMemberAttribute.
    /// And use DataMemberAttribute.IsRequired
    ///
    DataContract =1,

    ///
    /// Include all public classes decorated by JsonObjectAttribute,
    /// and public properties or fields decorated by JsonPropertyAttribute.
    /// And use JsonPropertyAttribute.Required
    ///
    NewtonsoftJson = 2,

    ///
    /// Include all public classes decorated by SerializableAttribute,
    /// and all public properties or fields
    /// but excluding those decorated by NonSerializedAttribute.
    /// And use System.ComponentModel.DataAnnotations.RequiredAttribute.
    ///
    Serializable = 4,

    ///
    /// Include all public classes, properties and properties.
    /// And use System.ComponentModel.DataAnnotations.RequiredAttribute.
    ///
    AspNet = 8,
}

默认值是opt-in的DataContract。您可以使用任何一种方法或方法的组合。

///
///
namespace DemoWebApi_DemoData_Client {
    export enum AddressType {Postal, Residential}

    export enum Days {Sat=1, Sun=2, Mon=3, Tue=4, Wed=5, Thu=6, Fri=7}

    export interface Address {
        Id?: string;
        Street1?: string;
        Street2?: string;
        City?: string;
        State?: string;
        PostalCode?: string;
        Country?: string;
        Type?: DemoWebApi_DemoData_Client.AddressType;
        Location?: DemoWebApi_DemoData_Another_Client.MyPoint;
    }

    export interface Entity {
        Id?: string;
        Name: string;
        Addresses?: Array;
    }

    export interface Person extends DemoWebApi_DemoData_Client.Entity {
        Surname?: string;
        GivenName?: string;
        BirthDate?: Date;
    }

    export interface Company extends DemoWebApi_DemoData_Client.Entity {
        BusinessNumber?: string;
        BusinessNumberType?: string;
        TextMatrix?: Array;
        Int3D?: Array;
        Lines?: Array;
    }
}

namespace DemoWebApi_DemoData_Another_Client {
    export interface MyPoint {
        X?: number;
        Y?: number;
    }
}

namespace DemoWebApi_Controllers_Client {

    export class Entities {
        httpClient: HttpClient;
        constructor(public baseUri?: string, public error?:
        (xhr: JQueryXHR, ajaxOptions: string, thrown: string) =>
        any, public statusCode?: { [key: string]: any; }){
            this.httpClient = new HttpClient();
        }

        /**
         * Get a person
         * GET api/Entities/{id}
         * @param {number} id unique id of that guy
         * @return {DemoWebApi_DemoData_Client.Person} person in db
         */
        GetPerson(id: number, callback: (data : DemoWebApi_DemoData_Client.Person) => any){
            this.httpClient.get(encodeURI(this.baseUri +
            'api/Entities/'+id), callback, this.error, this.statusCode);
        }

        /**
         * POST api/Entities
         * @param {DemoWebApi_DemoData_Client.Person} person
         * @return {number}
         */
        CreatePerson(person: DemoWebApi_DemoData_Client.Person,
        	callback: (data : number) => any){
            this.httpClient.post(encodeURI(this.baseUri +
            'api/Entities'), person, callback, this.error, this.statusCode);
        }

        /**
         * PUT api/Entities
         * @param {DemoWebApi_DemoData_Client.Person} person
         * @return {void}
         */
        UpdatePerson(person: DemoWebApi_DemoData_Client.Person, callback: (data : void) => any){
            this.httpClient.put(encodeURI(this.baseUri +
            'api/Entities'), person, callback, this.error, this.statusCode);
        }

        /**
         * DELETE api/Entities/{id}
         * @param {number} id
         * @return {void}
         */
        Delete(id: number, callback: (data : void) => any){
            this.httpClient.delete(encodeURI(this.baseUri +
            'api/Entities/'+id), callback, this.error, this.statusCode);
        }
    }

    export class Values {
        httpClient: HttpClient;
        constructor(public baseUri?: string, public error?:
        (xhr: JQueryXHR, ajaxOptions: string, thrown: string) => any,
        public statusCode?: { [key: string]: any; }){
            this.httpClient = new HttpClient();
        }

        /**
         * GET api/Values
         * @return {Array}
         */
        Get(callback: (data : Array) => any){
            this.httpClient.get(encodeURI(this.baseUri +
            'api/Values'), callback, this.error, this.statusCode);
        }

        /**
         * GET api/Values/{id}?name={name}
         * @param {number} id
         * @param {string} name
         * @return {string}
         */
        GetByIdAndName(id: number, name: string, callback: (data : string) => any){
            this.httpClient.get(encodeURI(this.baseUri +
            'api/Values/'+id+'?name='+name),
            callback, this.error, this.statusCode);
        }

        /**
         * POST api/Values
         * @param {string} value
         * @return {string}
         */
        Post(value: {'':string}, callback: (data : string) => any){
            this.httpClient.post(encodeURI(this.baseUri +
            'api/Values'), value, callback, this.error, this.statusCode);
        }

        /**
         * PUT api/Values/{id}
         * @param {number} id
         * @param {string} value
         * @return {void}
         */
        Put(id: number, value: {'':string}, callback: (data : void) => any){
            this.httpClient.put(encodeURI(this.baseUri +
            'api/Values/'+id), value, callback, this.error, this.statusCode);
        }

        /**
         * DELETE api/Values/{id}
         * @param {number} id
         * @return {void}
         */
        Delete(id: number, callback: (data : void) => any){
            this.httpClient.delete(encodeURI(this.baseUri +
            'api/Values/'+id), callback, this.error, this.statusCode);
        }
    }
}

提示

config.Formatters.JsonFormatter.SerializerSettings.ContractResolver =
     new Newtonsoft.Json.Serialization.CamelCasePropertyNamesContractResolver();

如果C＃中的相应名称是Pascal式格式，则属性名称和函数名称将是驼峰式格式。有关更多详细信息，请检查camelCasing或PascalCasing。

ReturnType DoSomething(Type1 t1, Type2 t2 ...)

是API函数，其余是传输的技术实现细节：TCP / IP，HTTP，SOAP，面向资源，基于CRUD的URI，RESTful，XML和JSON等。函数原型和一段API文档应该足以调用API函数。客户开发人员至少在操作成功时就不必关心传输的那些实现细节。仅当出现错误时，开发人员才需要关心技术细节。例如，在基于SOAP的Web服务中，您必须了解SOAP错误。在RESTful Web服务中，您可能必须处理HTTP状态代码和响应。
